Effects of Filters on Image Sharpness

There are many discussions on the internet about whether a filter in front of a lens reduces the sharpness.

It is obvious that by using a filter in backlight situations, by using a cheap low quality filter or by stacking two or more filters you will reduce the image quality.

But the question whether a single high quality filter will reduce the image sharpness even in situations with diffused light is not yet clearly answered. Therefore I did some tests by myself.

The tests were done with my Nikon D800E on a stable Gitzo tripod with self-timer and mirror-lock-up. Focus was done in live-view at max zoom on the center of the frame.

As a test object I used a flat wall at a medium distance of 5-10m:

Test Wall

First I tested the Zeiss 2.8/21mm ZF.2 wideangle lens with different filters.

Zeiss 21mm, no filter, f/8, 100% crop of the center:

Zeiss 21mm no filter

Zeiss 21mm, B+W 007 Neutral MRC F-Pro protection filter, f/8, 100% crop of the center:

Zeiss 21mm protection filter

Zeiss 21mm, B+W KSM C-POL MRC SLIM polfilter, f/8, 100% crop of the center:

Zeiss 21mm polfilter

Then I tested the Zeiss Otus 1.4/55mm standard lens with and without a filter.

Zeiss 55mm, no filter, f/5.6, 100% crop of the center:

Zeiss 55mm no filter

Zeiss 55mm, B+W 007 Clear MRC nano XS-Pro protection filter, f/5.6, 100% crop of the center:

Zeiss 55mm protection filter

Short conclusion: I don’t see any significant differences between the images shot with and without a filter. If I don’t see it in a 100% crop it shouldn’t matter on large prints.

Of course if I shoot against the sun I will still remove my filters but in all other situations I will not hesitate to use a protection filter (or a polfilter, if the situation requires this).

By the way, the main purpose of a protection filter is not to protect the lens from an impact but from dust, mud, fingerprints, cleaning marks and especially salt spray near the sea.
